Moticam A8

The fast sCMOS imaging setup of the Moticam A8 allows 4K resolution while still delivering steady 15fps. Printing images needs high-resolution data and this Moticam delivers the detail needed. The ideal camera, for everyone who has high demands and wants to stay flexible.
Product code
1100600101443
455.00€
Prices shown are the Manufacturer’s Suggested Retail Prices (MSRP) and may vary depending on the country. Prices do not include VAT, nor shipping, installation, insurance or any other additional services or taxes. Please note that the optical configuration of this specific model may differ from the objectives shown in the images.
Prices shown are the Manufacturer’s Suggested Retail Prices (MSRP) and may vary depending on the country. Prices do not include VAT, nor shipping, installation, insurance or any other additional services or taxes. Please note that the optical configuration of this specific model may differ from the objectives shown in the images.
Specifications
Model Moticam A8
Sensor Type sCMOS
Sensor Size 1/3"
Imaging Area 5.91mm (Diagonal)
Capture Resolution Info 8MP
Live display mode through USB 3840x2160,1920x1080 pixels
Pixel size 1.34x1.34μm
Scan mode Progressive
Shutter mode Rolling Shutter
Data transfer USB 2.0
Max. frames per second (fps) 3840x2160 @ 15fps, 1920x1080 @ 30fps (*)
Operating temperature From -10 to +60 Degrees Celsius non condensing
Sensitivity >2000mV
Support device TWAIN, SDK and Direct Show Driver
Supported OS Microsoft Windows 7/8/10, MAC OSX10.9, Linux UBUNTU1604 or higher
Minimum computer requirements 2GHz dualcore - RAM memory 2GB
Lens mount C-Mount
Focusable lens 12mm
Software MotiConnect for Windows/OSX/Linux (Download only)
Functions Still image and video capture, still image measurement, image adjustments, automatic and manual white balance, automatic and manual exposure, individual objective calibration system.
Power supply 5V (USB supply)
Package includes CS ring adaptor, focusable lens, 30mm and 38mm eyepiece adapters, USB 2.0 cable, Motic 4-dot calibration slide, macro tube, Calibration card
Other features (*) Frames per second under optimal lighting conditions and in compliance with computer technical requirements.

Catalogues

  • Moticam A Series - Catalogue File size: 900.94 KB
    Language: English
  • Moticam A8 - Flyer File size: 344.82 KB
    Language: English
  • MotiConnect App - Flyer File size: 4.09 MB
    Language: English

Specification sheets

  • Moticam A8 - SpecSheet File size: 209.81 KB
    Language: English

Images

MOTICAM A8 - IMG
Download
MOTICAM A8 - DETAIL1 - IMG
Download
MOTICAM A8 - IMG
Download

Moticam A Series Launch | by Motic Europe

Welcome to the next generation of Moticams! Immerse yourself in a world of discovery: whether you are a microscope beginner, a teacher, or an experienced scientist, we always have your back by offering you our new range of Moticam A. Investigate and analyze your images through the user-friendly MotiConnect software and get ready to be mindblown with the Alphas of Moticams!

MotiConnect App for computers - First steps | by Motic Europe

Here's how to get started with our free MotiConnect App for computers. You'll learn how to download and install the app, select your device for the first time, and a general overview of the main tools and features of this fantastic microscopy app.

Moticam A Series microscopy camera Unboxing | by Motic Europe

Wondering what's inside the box of the Moticam A series microscopy camera? In this unboxing video, we reveal what accessories are included and why we call this the “All-in-one box” concept.

Motic Images Plus 3.0 - First Steps tutorial | by Motic Europe

A friendly start: Learn how to make your first steps with Motic Images Plus 3.0 software. From software installation up to making professional measurements, we guide you step by step through getting a great live image, applying image adjustments to see the microscope's image as wished or the most closely to eyepiece observation, and capturing an image or video. All you might need to start with confidence. This tutorial is also valid for the 3.1 software version.

Moticams: Let´s talk about them! | Motic Chats | by Motic Europe

Today we will talk about Moticams: what are they, how to use them and how to pimp up standard microscopes!

Motic Images Plus 3.0 - Calibration tutorial | by Motic Europe

Calibration simply explained: Learn how to calibrate Motic Image Plus 3.0 software, a must in professional environments where exact scale and measurements are a daily need. Easy to follow step-by-step explanation with tips & tricks to perform it accurately. This tutorial is also valid for the 3.1 version of the software.
